Ubiquiti Unifi Standard 24 Port Switch
UniFi Standard 24 – Silent 24-Port Gigabit Switch with SFP Uplinks
The UniFi Standard 24 is a 24-port Layer 2 switch designed to deliver reliable gigabit connectivity in a quiet, fanless design. With 24 GbE ports and two 1G SFP uplinks, it provides versatile switching options for small to medium-sized networks.
Its silent cooling system makes it an excellent choice for offices, classrooms, retail environments, and hospitality deployments where noise levels must be kept to a minimum. Compact and wall-mountable, the UniFi Standard 24 integrates seamlessly into UniFi-managed networks for centralised monitoring and configuration.
Offering dependable performance, flexible uplinks, and whisper-quiet operation, the UniFi Standard 24 is a cost-effective solution for expanding wired UniFi infrastructure.
Any EU products are supplied with the appropriate UK power method at no extra cost.
Tech Specs
| Device Specifications | |
|---|---|
| Overview | |
| Dimensions | 442 x 200 x 44 mm (17.4 x 7.9 x 1.7") |
| Port Layout | 1 GbE RJ45 24 (1G/100M/10M) 1G SFP 2 (1G) |
| Form Factor | Rack mount (1U) |
| Performance | |
| Switching Capacity | 52 Gbps |
| Total Non-Blocking Throughput | 26 Gbps |
| Forwarding Rate | 39 Mpps |
| Supported VLANs | 1,000 |
| MAC Address Table Size | 8,000 |
| Packet Buffer Size | 0.5 MB |
| Access Lists | IPv4: 128 MAC: 128 |
| Layer 2 Features | |
| LACP Port Aggregation | ✓ |
| STP & RSTP | ✓ |
| Advanced IGMP Configuration | ✓ |
| IGMP Snooping | ✓ |
| 802.1X Control | ✓ |
| MAC-Based ACLs & Device Isolation | ✓ |
| DHCP Snooping & Guarding | ✓ |
| Egress Rate Limit | ✓ |
| Flow Control | ✓ |
| Storm Control | ✓ |
| Multicast & Broadcast Rate Limiting | ✓ |
| MAC Address Blocking | ✓ |
| IP-Based ACLs & Network Isolation | ✓ |
| MAC-Based Port Restriction | ✓ |
| Port Isolation | ✓ |
| Port Mirroring | ✓ |
| Jumbo Frames | ✓ |
| LLDP-MED | ✓ |
| Voice VLAN | ✓ |
| Loop Protection | ✓ |
| Hardware | |
| Max. Power Consumption | 25W |
| Power Method | Universal input, 100—240V AC, 50/60 Hz |
| Power Input Method | AC input |
| Power Supply | AC/DC, internal, 36W |
| Supported Voltage Range | 100—240V AC |
| Management | Ethernet AR |
| Heat Dissipation | 85.3 BTU/hr |
| Weight | Without mounting brackets: 2.7 kg (6 lb) With mounting brackets: 2.8 kg (6.2 lb) |
| Enclosure Material | SGCC steel |
| Mount Material | SGCC steel |
| Supported Rack Depth | 400~1200 mm (15.7-47.2") |
| LCM Display | 1.3" touchscreen |
| Ambient Operating Temperature | -5 to 45° C (23 to 113° F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| NDAA Compliant | ✓ |
| Certifications | CE, FCC, IC, Anatel |
| Software | |
| Application Requirements | UniFi Network Version 7.2.94 and later |
FAQs
Q: What is the Ubiquiti USW-24 used for?
A: The USW-24 is a fully managed Layer 2 UniFi switch designed to provide 24 Gigabit Ethernet connections with enterprise-grade switching performance.
Q: How many uplink ports does the USW-24 include?
A: The switch has 24 Gigabit RJ45 ports for devices and 2 SFP ports for fiber uplinks or inter-switch connectivity.
Q: Does the USW-24 support PoE?
A: No, the USW-24 is a standard model without PoE support. For powering UniFi access points or cameras, PoE-enabled models such as the USW-24-PoE are required.
Q: How is the Ubiquiti USW-24 managed?
A: It is fully managed through the UniFi Network Application, enabling VLAN configuration, traffic monitoring, and remote firmware management.
Q: Is the Ubiquiti USW-24 silent in operation?
A: Yes, the USW-24 uses a fanless design, providing quiet operation suitable for offices, classrooms, and retail environments.
Resources
Guide: UniFi Network for Retail and Hospitality — MS Dist
Guide: Setting Up a Ubiquiti UniFi Network for a Small Office or Business — MS Dist
Original: $282.56
-70%$282.56
$84.77More Images
