Ubiquiti UniFi PoE Smart Chime
UniFi PoE Smart Chime – PoE Notification Chime for UniFi Door Systems
The UniFi PoE Smart Chime is a plug-and-play notification device designed to pair seamlessly with a UniFi doorbell or UniFi Access hub. It provides clear, instant audible alerts for doorbell rings or access events, making it ideal for homes, offices, reception areas, and commercial environments.
Powered and connected via PoE, the Smart Chime offers simple installation with no additional power adapters required. Its built-in speaker delivers sound levels of up to 80 dB, ensuring notifications are clearly heard across busy or open spaces while remaining fully managed within the UniFi platform.
Tech Specs
| Device Specifications | |
|---|---|
| Mechanical | |
| Dimensions | Device: Ø62 x 54 mm (Ø2.5 x 2.1") In-wall mount: Ø89 x 63.1 mm (Ø3.5 x 2.5") On-wall mount: Ø62 x 20.2 mm (Ø2.5 x 0.8") |
| Weight | Device: 158 g (5.6 oz) In-wall mount: 91 g (3.2 oz) On-wall mount: 28 g (1 oz) |
| Enclosure Material | Polycarbonate, aluminum alloy |
| Mount Material | Polycarbonate, zinc alloy |
| Hardware | |
| Networking Interface | 10/100 MbE port |
| Power Method | PoE |
| Supported Voltage Range | 44–57V DC |
| Max. Power Consumption | 3W |
| ESD/EMP Protection | Air: ±8kV, contact: ±4kV |
| LED | R/G/B/W |
| Button | Factory reset |
| Ambient Operating Temperature | 0 to 40° C (32 to 104° F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| NDAA Compliant | Yes |
Original: $97.55
-70%$97.55
$29.26More Images
Ubiquiti UniFi PoE Smart Chime
UniFi PoE Smart Chime – PoE Notification Chime for UniFi Door Systems
The UniFi PoE Smart Chime is a plug-and-play notification device designed to pair seamlessly with a UniFi doorbell or UniFi Access hub. It provides clear, instant audible alerts for doorbell rings or access events, making it ideal for homes, offices, reception areas, and commercial environments.
Powered and connected via PoE, the Smart Chime offers simple installation with no additional power adapters required. Its built-in speaker delivers sound levels of up to 80 dB, ensuring notifications are clearly heard across busy or open spaces while remaining fully managed within the UniFi platform.
Tech Specs
| Device Specifications | |
|---|---|
| Mechanical | |
| Dimensions | Device: Ø62 x 54 mm (Ø2.5 x 2.1") In-wall mount: Ø89 x 63.1 mm (Ø3.5 x 2.5") On-wall mount: Ø62 x 20.2 mm (Ø2.5 x 0.8") |
| Weight | Device: 158 g (5.6 oz) In-wall mount: 91 g (3.2 oz) On-wall mount: 28 g (1 oz) |
| Enclosure Material | Polycarbonate, aluminum alloy |
| Mount Material | Polycarbonate, zinc alloy |
| Hardware | |
| Networking Interface | 10/100 MbE port |
| Power Method | PoE |
| Supported Voltage Range | 44–57V DC |
| Max. Power Consumption | 3W |
| ESD/EMP Protection | Air: ±8kV, contact: ±4kV |
| LED | R/G/B/W |
| Button | Factory reset |
| Ambient Operating Temperature | 0 to 40° C (32 to 104° F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| NDAA Compliant | Yes |
