Ubiquiti UniFi Lite 16 Port PoE Switch
UniFi Lite 16 PoE – Fanless 16-Port Gigabit PoE Switch for Quiet Deployments
The UniFi Lite 16 PoE is a compact, Layer 2 switch designed to deliver reliable gigabit connectivity and efficient PoE power in small to medium UniFi deployments. Featuring eight GbE PoE+ ports and eight standard GbE ports, it provides a total PoE budget of 45W for powering UniFi access points, cameras, or VoIP phones.
Built with a silent fanless cooling system, the Lite 16 PoE is ideal for noise-sensitive environments such as offices, classrooms, retail spaces, and hospitality venues. Its wall-mountable design allows flexible installation while maintaining a clean and discreet appearance.
Fully managed through the UniFi Network application, the UniFi Lite 16 PoE offers simple setup, centralised management, and dependable Layer 2 switching in a space-saving form factor.
Any EU products are supplied with the appropriate UK power method at no extra cost.
Tech Specs
Click here for the USW-Lite-16-PoE datasheet.
| Device Specifications | |
|---|---|
| Overview | |
| Dimensions | 192 x 185 x 44 mm |
| Port Layout | 1 GbE RJ45 16 (8 PoE+) (1G/100M/10M) |
| Max. PoE Output | Up to PoE+ |
| Total PoE Availability | 45W |
| Form Factor | Compact desktop, wall |
| Performance | |
| Switching Capacity | 32 Gbps |
| Total Non-Blocking Throughput | 16 Gbps |
| Forwarding Rate | 24 Mpps |
| Supported VLANs | 1,000 |
| MAC Address Table Size | 8,000 |
| Packet Buffer Size | 0.5 MB |
| Access Lists | IPv4: 128 MAC: 128 |
| Layer 2 Features | |
| Features | LACP Port Aggregation ✓ STP & RSTP ✓ Advanced IGMP Configuration (Querier, Fast Leave, Router Port) ✓ IGMP Snooping ✓ 802.1X Control ✓ MAC-Based ACLs & Device Isolation ✓ DHCP Snooping & Guarding ✓ Egress Rate Limit ✓ Flow Control ✓ Storm Control ✓ Multicast & Broadcast Rate Limiting ✓ MAC Address Blocking ✓ IP-Based ACLs & Network Isolation ✓ MAC-Based Port Restriction ✓ Port Isolation ✓ Port Mirroring ✓ Jumbo Frames ✓ LLDP-MED ✓ Voice VLAN ✓ Loop Protection ✓ |
| Hardware | |
| PoE Ports | PoE+ 8 |
| Max. PoE Wattage per Port by PSE | PoE+ 32W |
| Max. Power Consumption | 15W (Excluding PoE Output) 60W (Including PoE Output) |
| Power Method | Universal input, 100—240V AC, 50/60 Hz |
| Power Input Method | AC input |
| Power Supply | AC/DC, internal, 60W |
| Supported Voltage Range | 100—240V AC |
| Management | Ethernet |
| Heat Dissipation (Excluding PoE Output) | 51.18 BTU/hr |
| Weight | 1.2 kg (2.6 lb) |
| Enclosure Material | Polycarbonate |
| Mount Material | Polycarbonate |
| Supported Rack Depth | 400~1200 mm (15.7-47.2") |
| Ambient Operating Temperature | -15 to 40° C (5 to 104° F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| NDAA Compliant | ✓ |
| Certifications | CE, FCC, IC, Anatel |
| Software | |
| Application Requirements | UniFi Network Version 7.2.94 and later |
FAQs
Q: What is the Ubiquiti USW-Lite-16-PoE used for?
A: The USW-Lite-16-PoE is a 16-port Gigabit UniFi switch designed to deliver both data and PoE+ power to multiple UniFi devices, such as access points, cameras, and VoIP phones.
Q: How many PoE ports does the USW-Lite-16-PoE have?
A: All 16 ports support 802.3af/at PoE+, providing flexible power to a wide range of devices.
Q: What is the total PoE budget of the USW-Lite-16-PoE?
A: The switch offers up to 150W total PoE power, sufficient for powering multiple high-demand UniFi devices simultaneously.
Q: Can the USW-Lite-16-PoE be managed via software?
A: Yes, it integrates with the UniFi Network Application for VLAN configuration, port monitoring, traffic analytics, and remote firmware updates.
Q: Is the USW-Lite-16-PoE fanless and quiet?
A: Yes, it has a fanless design for silent operation, ideal for offices, retail, and other noise-sensitive indoor environments.
