Ubiquiti UniFi G4 Doorbell Professional PoE Kit
The Ubiquiti G4 Doorbell Professional PoE Kit comes with a built-in PoE and a PoE chime for easy setup. It boasts enhanced HDR and low-light capabilities, along with a programmable welcome display and a secondary camera for package detection. Utilising PoE, this doorbell also offers 2-way audio and is weather-resistant for outdoor use.
Tech Specs
Click here for the UniFi G4 Doorbell Professional PoE Kit datasheet.
| Device Specifications | |
|---|---|
| Overview | |
| Dimensions | Device: 160.6 x 51.7 x 35.1 mm (6.3 x 2 x 1.4") Wall mount: 159.3 x 50.3 x 17.5 mm (6.3 x 1.9 x 0.7") Wedge: 161.1 x 52.1 x 25.7 mm (6.3 x 2.1 x 1") On-wall mount: 161.1 x 52.1 x 25.75 mm (6.3 x 2.1 x 1") |
| IR Night Vision | 6 m (20 ft) |
| Smart Detections | People, Vehicles, Animals ✓ |
| Resolution | FHD |
| Field of View | Main camera: H: 138°, V: 114°, D: 155° (LDC On) Main camera: H: 160°, V: 117°, D: 160° (LDC Off) Package camera: H: 97.5°, V: 79.4°, D: 118.2° |
| Audio | Two-way audio |
| Weatherproofing | IPX4 |
| Mounting | Wall, wedge (Included) Gang box, junction box (Optional) |
| Performance | |
| Networking Interface | GbE RJ45 port |
| Max. Frame Rate | 30 FPS |
| Resolution | Main camera: 2MP 1600 x 1200 (4:3) Package camera: 2MP 1600 x 1200 (4:3) |
| Optics Sensor | Main camera: 5MP CMOS Package camera: 8MP CMOS |
| Lens | Fixed focal length |
| Night Mode | Built-in IR LED illumination and IR cut filter |
| Hardware | |
| Max. Power Consumption | 7W |
| Supported Voltage Range | 37—57V DC |
| Power Method | PoE |
| Processor | Quad-core Arm® Cortex®-A53 based chip |
| Weight | Device: 264 g (9.3 oz) Wall mount: 56 g (2 oz) Wedge: 33 g (1.2 oz) On-wall mount: 53 g (1.9 oz) |
| Enclosure Material | Polycarbonate, aluminum alloy |
| Mount Material | Flat wall mount: aluminum alloy 20° wedge mount: polycarbonate |
| Button | (1) Ring button (1) Factory-reset |
| Ambient Operating Temperature | -30 to 40º C (-22 to 104º F) |
| Ambient Operating Humidity | 0 to 90% noncondensing |
| NDAA Compliant | ✓ |
| Certifications | CE, FCC, IC, SRRC |
| Software | |
| Mobile App | UniFi Protect iOS™ and Android™ |
| Chime | |
| Dimensions | Device: Ø62 x 54 mm (Ø2.5 x 2.1") In-wall mount: Ø89 x 63.1 mm (Ø3.5 x 2.5") On-wall Mount: Ø62 x 20.2 mm (Ø2.5 x 0.8") |
| Weight | Device: 158 g (5.6 oz) In-wall mount: 91 g (3.2 oz) On-wall mount: 28 g (1 oz) |
| Enclosure Material | Polycarbonate, aluminum alloy |
| Mount Material | Polycarbonate, zinc alloy |
| Networking Interface | 10/100 MbE port |
| Power Method | PoE |
| Supported Voltage Range | 44—57V DC |
| Max. Power Consumption | 3W |
| LED | R/G/B/W |
| Buttons | (1) Factory-reset |
| Speaker | Yes |
| Buzzer | Yes |
| Ambient Operating Temperature | 0 to 40° C (32 to 104° F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| NDAA Compliant | ✓ |
FAQs
Q. What type of device is the Ubiquiti UVC-G4 Doorbell Pro PoE Kit?
A: The UVC-G4 Doorbell Pro PoE Kit is a networked smart doorbell with HD video, AI-based detection, and two-way audio for monitoring entrances in residential or commercial settings.
Q. What AI features does the UVC-G4 Doorbell Pro PoE Kit include?
A: It provides AI-powered person detection, motion alerts, and intelligent notifications, helping reduce false alarms and ensuring accurate monitoring.
Q. What video resolution and streaming formats does the doorbell support?
A: The UVC-G4 Doorbell Pro supports HD video streaming with H.264 and H.265 encoding for high-quality video and efficient bandwidth usage.
Q. How does the UVC-G4 Doorbell Pro integrate with UniFi Protect?
A: The doorbell integrates seamlessly with UniFi Protect, enabling live view, recorded video access, motion alerts, and AI analytics directly through the platform.
Q. What networking and power options are available for the UVC-G4 Doorbell Pro PoE Kit?
A: The kit uses Gigabit Ethernet with PoE (Power over Ethernet), providing both data and power through a single cable for simplified installation and reliable connectivity.
