Ubiquiti UniFi AI Theta Pro 360 Lens
This lens offers a 360° view with improved low-light capabilities and dynamic range when connected to an AI Theta Hub. Notable features include 4K resolution (8MP) and exceptional image quality, making it ideal for capturing panoramic views of busy areas like entrances, lobbies, and retail floors. It includes a Standard Flush Mount for easy installation on flat ceilings or walls and is compatible with AI Theta Pro Mounts.
Tech Specs
| Device Specifications | |
|---|---|
| Overview | |
| Dimensions | Ø36.6 x 58.9 mm (Ø1.4 x 2.3”) |
| Field of View | H: 180°, V: 180°, D: 180° |
| Resolution | 4K |
| Mounting | Wall, ceiling mount (Included) Flush mount (Optional) |
| Operating Environment | Indoor only |
| Performance | |
| Video Image Settings | Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay |
| Max. Frame Rate | 24 FPS |
| Resolution | 4MP 2160 x 2160 (1:1) |
| Sensor | 8MP 1/1.8" |
| Lens | Fixed focal length |
| Hardware | |
| Enclosure Material | Aluminum alloy, polycarbonate |
| Mounting Material | Polycarbonate |
| Weight | 58 g (2 oz) |
| Power Method | Theta proprietary |
| Power Supply | 5V DC, 0.5A |
| Max. Power Consumption | 2.5W |
| Ambient Operating Temperature | 0 to 40° C (32 to 104° F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| Certifications | FCC, IC, CE |
FAQs
Q: What is the Ubiquiti UVC-AI-Theta-ProLens360 and what is it designed for?
A: The UVC-AI-Theta-ProLens360 is a professional-grade ultra-wide 360° ceiling lens designed to connect to an AI Theta Hub. It provides enhanced low-light performance and dynamic range, making it ideal for capturing detailed footage in large indoor spaces such as retail environments or expansive hallways.
Q: What are the optical specifications of the UVC-AI-Theta-ProLens360?
A: This lens features an 8MP 1/1.8" sensor with a fixed focal length, delivering 4MP (2160 x 2160) resolution at 24 fps. It offers a horizontal, vertical, and diagonal field of view of 180°, providing clear and detailed images across a wide area.
Q: What are the physical and environmental specifications?
A: The lens measures Ø36.6 x 58.9 mm (Ø1.4 x 2.3 in.) and weighs 58 g (2 oz). It is constructed from aluminum alloy and polycarbonate materials, ensuring durability. The lens is designed for indoor use only and is compatible with AI Theta Pro mounts.
Q: How is the UVC-AI-Theta-ProLens360 powered and managed?
A: The lens connects to an AI Theta Hub, which provides the necessary power and management capabilities. The AI Theta Hub facilitates seamless integration with UniFi Protect, allowing for centralized control and monitoring of connected devices.
Q: What are the video compression and resolution capabilities?
A: The UVC-AI-Theta-ProLens360 supports H.264 video compression, delivering high-quality 4MP (2160 x 2160) video resolution at 24 fps. This ensures detailed and smooth video playback, suitable for various surveillance applications.
